**Scroll Down to see Pictures and Video!**
Sizes and Weights:
Telescopic:
- 7′ Wide x 12′ Long (12K and 14K GVW)
- 7′ Wide x 14′ Long (14K and 16K GVW)
- 7′ Wide x 16′ Long (14K and 16K GVW)
Scissors:
- 7′ Wide x 12′ Long (12K and 14K GVW)
- 7′ Wide x 14′ Long (14K and 16K GVW)
- 7′ Wide x 16′ Long (14K and 16K GVW)
**The dual hoist model has been discontinued and is no longer available**
Highlighted Features:
- Integrated Side Body Stiffening System
- Integrated Tarp Mount w/ Mesh Tarp Kit Pre Installed (Now Standard!)
- Underbody Secure Tool Storage
- Combo Barn Door Spreader Gate with Cambar
- All LED Lights
- HD Slipper Springs
- Sealed Brake Connections
- Ramps (Stored Underneath Bed)
Standard Features:
- 82″ Inside Bed Width
- Welded Tubular Steel Main Frame
- 10 Gauge Floor
- (4) Wheel Electric Brakes
- Slipper Spring Axles with Easy Lube Hubs
- 45 Degree Dump Angle
- Power Up, Power Down on Dual Ram Units
- Power Up, Gravity Down on Scissor and Telescopic Units
- (5) D-Rings
- (3) Stake Pockets Per Side
- Stabilizer Jack Receivers (Jacks Optional)
- Side Steps
- Ramps (Stored Underneath Bed)
- Adjustable 2 5/16″ Coupler
- Spare Tire Bracket
- Combination Barn Door and Spreader Gate
- Bead Blasted, Iron Phosphate Washed
- Powder Coat Finish
- Integrated Side Body Stiffening System
- ST235/80R16 LRE Tires
- Deep Cycle Marine Grade Battery Included
- 7 Way RV Style Electrical Plug
- Tongue Mounted HD Control Box w/ key lock
- LED Lights With Sealed Wiring Harness
- 7K Drop Leg Set Back Jack on 12K and 14K Models
- 12K Drop Leg Set Back Jack on 16K Models
Optional Features:
- HD 12K Drop Leg Jack (Standard on 16K Models)
- Rear Stabilizer Jacks (A Must have for Loading Heavy Equipment)
- Pintle Eye (No Charge)
- 48″ High Sides
- Wireless Dump Remote
- Aluminum Wheel Upgrade
